AA-55-ZOOM antenna analyzer

Description RigExpert AA-55 ZOOM The analyzer is designed for measuring SWR (standing wave ratio), return loss, cable loss, as well as other parameters of cable and antenna systems in the range of 60 kHz to 55 MHz. A built-in ZOOM capability makes graphical measurements especially effective. The following tasks are easily accomplished by using this analyzer: Rapid check-out of an antenna Tuning an antenna to resonance Comparing characteristics of an antenna before and after specific event (rain, hurricane, etc.) Making coaxial stubs or measuring their parameters Cable testing and fault location, measuring cable loss and characteristic impedance Measuring capacitance or inductance of reactive loads Warranty coverage by the RigExpertCare™ The RigExpertCare™ 2-year warranty coverage The device which has stopped functioning due to factory defects within the Warranty period will be replaced by a new one in a very few days instead of waiting when it’d be fixed. Just contact the RigExpertCare™ partner to get such a great support! What is the RigExpertCare™ protection RigExpertCare™ is the 2-years limited warranty coverage for RigExpert™ products. RigExpertCare™ means that the Rig Expert Ukraine will replace defective goods covered by the Warranty with the new goods of the same model as soon as possible. Important Conditions Rig Expert Ukraine Ltd. will replace any product that has been proven to have a manufacturing defect. RigExpertCare™ applies when the product has been used for the purpose intended and under normal conditions. General wear and tear, normal fading, and accidental damage is not covered by the warranty. Replacement will be performed by the RigExpertCare™ partner. To get a replacement please contact nearest RigExpertCare™ partner specified here. To check whether your instrument is covered by the RigExpertCare™ see special sticker on the top of product package or visit the RigExpert™ website and find notice “Warranty coverage by the RigExpertCare™” on General info tab at the product page. Who Is Covered Under the Warranty The warranty is non-transferable. Only the original customer is covered under the RigExpertCare™ warranty. Proof of Purchase In rare cases, when warranty repair is required, the RigExpertCare™ partner may require confirmation of an official purchase (for example, purchase receipt etc.) What is Not Covered Under the Warranty The warranty does not apply to a product which has been damaged due to accident, misuse, abuse, improper installation, usage not in accordance with product specifications and instructions, natural or personal disaster, or unauthorized alterations, repairs or modifications. The warranty does not cover any events including but not limited to: Any damages unrelated to manufacturing defects. Damage, deterioration or malfunction resulting from: accident, abuse, misuse, neglect, fire, water, lightning, or other acts of nature, commercial or industrial use, unauthorized product modification or failure to follow instructions included with the product. Repair or attempted repair by anyone not authorized by Rig Expert Ukraine Ltd. Any shipment damages (claims must be made with the carrier). Any unsuitable environment or use of the product in Rig Expert Ukraine opinion. Any product which has been modified without official permission from Rig Expert Ukraine Ltd., or on which the serial number or warranty sticker has been defaced, modified, or removed. Shipping Customers are responsible for shipping costs to ship back the defective item for RMA repair/replace. Once the faulty item is received by RigExpertCare™ partner a new replaced item will be shipped back to the customer. Shipping methods will be at Rig Expert’s discretion. Therefore, RigExpertCare™ partner reserves the rights to ship according to what it deems the most efficient standard method of shipping. Important addition Rig Expert Ukraine Ltd. can repair defective goods at the Customer’s request. To get a warranty repair please contact your original seller. RigExpert AA-55 ZOOM. Specifications. Frequency range: 0.06 to 55 MHz Frequency entry: 1 kHz resolution Measurement for 25, 50, 75, 100, 150, 200, 300, 450 and 600-Ohm systems SWR measurement range: 1 to 100 in numerical modes, 1 to 10 in chart modes SWR display: numerical or analog indicator R and X range: 0…10000, -10000…10000 in numerical modes, 0…1000, -1000…1000 in chart modes Display modes: – SWR at single or multiple frequencies – SWR, return loss, R, X, Z, L, C and phase angle at single frequency – SWR chart, 100 points – R, X chart, 100 points – Smith chart, 100 points – Return loss chart, 100 points – Cable tools (loss and characteristic impedance) Optional open-short-load calibration. Non Volatile memory: – 10 slots to save measurement results RF output: – Connector type: UHF (SO-239) – Output signal shape: square, 0.06 to 55 MHz – Output power: 13 dBm (at 50 Ohm load) Power: – Two 1.5V alkaline batteries, type AA – Max. 4 hours of continuous measurement, max. 2 days in stand-by mode when fully charged batteries are used – When the analyzer is connected to a PC or a DC adapter with USB socket, it takes power from these sources Interface: – 320×240 color TFT display – 6×3 keys on the water-proof keypad – Multilingual menus and help screens – USB connection to a personal computer Bluetooth specs.: The AA-55 Zoom analyzer has two versions of the installed Bluetooth module: – Bluetooth Classic. Firmware version 1.** This Bluetooth protocol is supported only by devices running the Android operating system (older than version 4.0). There is also limited support at Windows and Linux. – Bluetooth Low Energy (BLE). Firmware version 2.** This Bluetooth protocol is supported by gadgets running Android and iOS operating systems. There is no support for analyzers with the BLE module in the Windows, Linux, and macOS operating systems of the analyzers with the BLE module (at the moment). Dimensions: 103 mm x 207 mm x 37 mm (4.1 in x 8.1 in x 1.4 in) Operating temperature: 0…40 °C (32…104 °F) Weight: 310 g (10.9 Oz) w/o batteries Warranty: 2 years GTIN-13: 4820185420099 RigExpert AA-55 ZOOM is made in Ukraine. Specifications are subject to change without notice. RigExpert AA-55 ZOOM. How it works? Structure diagram The structure diagram of RigExpert AA-55 ZOOM is located below: The “brain” of the analyzer is STM 32-bit RISC microcontroller. It controls a Si5351 PLL chip running at 500 MHz and generating two sinusoidal signals. Both signals are low-pass filtered and then put through pulse shapers, producing two square signals with CMOS levels. Resistive brigde was chosen to measure parameters of a load because of its simplicity and good frequency response. The switch commutates two outputs of the bridge. After the switch, the signal is mixed with the second channel output to produce audio frequency of 1.5 kHz.This signal is then filtered and fed on the 12-bit ADC of the microcontroller. The 320×240 color TFT display and the 6×3 keys keypad are connected directly to the CPU. The USB interface allows connecting the analyzer to the PC. Close look at the bridge This is a diagram of the resistive bridge and its connection to the mixer: The switch which is controlled by the CPU feeds the signal from the certain side of the bridge to the mixer chip. When the load is totally active and its resistance is 50 ?, the bridge is balanced and the switch outputs the same signal in both positions. This eliminates the need of calibration of the analyzer, also giving very good precision near SWR=1. RigExpert AA-55 ZOOM. In the package. Included: RigExpert AA-55 ZOOM Soft case USB cable User’s manual Alkaline batteries   RigExpert AA-55 ZOOM. Downloads. AntScope2 for Windows & MacOS: Click for downloading the latest version of the Antscope2 for your Windows PC. Click for downloading the latest version of the Antscope2 for your MacOS. Flash Tool for Mac or Windows: Please download and run the Firmware update tool for Windows. Please download and run the Firmware update tool for MacOS. User’s & Software Manuals: Click for opening the User’s manual, in English. Click for opening the Software manual in English. Product brief Brochure in English
